Access Control Power

Power Supply Control ST-P04

Output voltage：DC12V
Input voltage：220V
Time Delay：0~15sec.
Suitable For：Access control Electric lock Magnetic Lock Building intercom system
Access control power Supply Manual Wide dinput voltage rangesmall size high reliability electromagnetic compatibility high efficiency size high reliability electromagnetic compatibility high efficiency protection functionwith remote door te
INQUIRY

Size	185mm78mm65mm
ripple voltage	Up ≤ 50mV
Input voltage	AC 220V
Input Frequency	50Hz
Output voltage	DC12V
Output current	3A/5A
Output voltage trim range	+_10%~+_15%
Load stability	1%typical
Time Delay	0~15sec.
Weight	approx. 1.5Kg
Output Contact	Access control, Electric Lock, Release Button, Magnetic Lock
Output stability	0.5% typical
Hold time	at full load typ 20ms
Working temperature	-20~+65°C
Standard Designe	Steel material, Painted
Protect Safely	Short Circuit protection
Suitable For	Access control, Electric lock, Magnetic Lock, Building intercom system,
Warranty	12months
Features	1.Output: GND and NC all the way to control the voltage output no load around 15 volts.12V load.(Connect Electric lock) Steady voltage output 12V/1A (connect controller or card reader) GND and NC all the way to control the voltage output no load around 15 volts.12V load.(Connect Electric lock) 2. Steady voltage output 12V/1A (connect controller or card reader) 3.Direct control of electric locks:The load of the access controller can be reduced, the wiring of the engineering can be saved, and hidden troubles can be reduced. 4.Directly input 12V voltage to open the door 5.Set open button input: The door button and wireless button can be accessed. Directly open the electric lock, automatic protection function.
